Fitment at a Glance

Here's the short version before the deep dive. Every 4Runner from 1984 to today runs a 6x139.7mm (6x5.5") bolt pattern. Nothing changed there. What did change is the 6th gen: for 2025 and up, Toyota shrank the hub bore from 106.1mm down to 95.1mm and moved from M12x1.5 studs to M14x1.5. That means 5th gen wheels don't bolt on a 6th gen truck without modification. Get the pattern, bore, and stud pitch right for your generation and everything else is stance and tire choice.

Bolt Pattern (PCD)

 6x139.7mm (6x5.5")

*Gen 1-2 uses 5x114.3

Thread Pitch

M12x1.5 (4th + 5th gen)

Center Bore

06.1mm (4th + 5th gen

95.1mm (6th gen)

Popular Setup

17x9, -12 to +0 offset

OEM TOYOTA 4RUNNER WHEEL & TIRE SPECS

Before you shop aftermarket, it helps to know what came from the factory across each generation. The 4Runner ships different wheels depending on trim and year, and stock offsets sit deep in the tucked range, which is why factory 4Runners always look like they've got room in the fenders.

4th gen (2003–2009)

The 4th gen came with 16-inch, 17-inch, or 18-inch factory wheels depending on trim, all riding on high +25 to +30 offsets with 265-series tires. Practical, capable, and the platform the whole modern 4Runner aftermarket built around.

5th gen (2009–2024)

The 5th gen kept the same 6x139.7 pattern, 106.1mm bore, and M12x1.5 studs as the 4th gen, so wheels cross-fit between the two generations. Factory sizes ran from 17x7 on the base and TRD Off-Road up to 20-inch on Limited, and the offsets dropped noticeably compared to the 4th gen. Most of the run sits around +15, with the earliest 5th gens dipping as low as +4. That lower offset is why 5th gens look a little more filled-out from the factory than 4th gens do.

6th gen (2025+)

The 6th gen is where the spec sheet shifts. Bolt pattern stays 6x139.7, but the hub bore dropped to 95.1mm and the studs went up to M14x1.5. Factory wheels run 17s, 18s, and 20s across the trims, with offsets jumping way back up to +45, +50, and +55, deeper into the tucked range than any 4Runner in the last 15 years. That leaves a lot of room to pull the stance out with aftermarket.

2003–2009 4Runner — 4th Gen (N210) 6x139.7 (6x5.5) • 106.1mm Bore • M12x1.5
WheelOffsetTire
16x7+30265/70R16
17x7.5+30265/65R17
18x7.5+25265/60R18
2009–2024 4Runner — 5th Gen (N280) 6x139.7 (6x5.5) • 106.1mm Bore • M12x1.5
WheelOffsetTire
17x7+4265/70R17
17x7+15245/70R17
17x7+15265/70R17
17x7.5+15265/70R17
18x7+15265/60R18
20x7+15245/60R20
2024–2027 4Runner — 6th Gen (N500) 6x139.7 (6x5.5) • 95.1mm Bore • M14x1.5
WheelOffsetTire
17x7+50245/70R17
18x7.5+55245/70R18
18x7.5+55265/70R18
20x8+45265/55R20

TOYOTA 4RUNNER WHEEL FITMENT

This is where a bad purchase happens, and where the 6th gen 4Runner throws people a curveball. 4Runner wheel fitment comes down to four numbers: bolt pattern, hub bore, offset, and width. Nail all four and the wheel sits right, clears the brakes, and runs smooth. Miss one and you're chasing a vibration or holding a wheel that won't seat.

Bolt pattern: unchanged across every generation

Every 4Runner from 1984 to now runs a 6x139.7mm bolt pattern, the same six-lug pattern used on the Tacoma and Tundra. That part is easy. Any wheel built for a six-lug Toyota truck has the right hole pattern for your 4Runner.

Hub bore and studs: the 6th gen changed the rules

For fifteen years, from 2010 to 2024, the 5th gen ran a 106.1mm hub bore with M12x1.5 studs. The 4th gen used the same setup, so 4th and 5th gen wheels are cross-compatible without adapters. Then Toyota launched the 6th gen in 2025 and changed both: the hub bore dropped from 106.1mm to 95.1mm, and the studs went from M12x1.5 to M14x1.5.

That means 5th gen wheels do not bolt on a 6th gen 4Runner without modification. The bore is too big for the smaller hub (they'd sit lug-centric, which on a truck this heavy is how you get a vibration you can't balance out), and the M12 lug holes won't accept the thicker M14 studs. Two ways to fix it: buy wheels made specifically for the 6th gen (machined to 95.1mm and drilled M14 out of the box), or have your existing 5th gen wheels drilled out to the new stud size and add hub-centric rings to bring the bore down. Most wheel manufacturers offer both options now.

Wheels built specifically for the 6th gen, like the 6th gen fitments in our own lineup, are machined to 95.1mm and drilled M14x1.5 from the factory. Nothing to adapt, seats hub-centric out of the box.

Offset: where the stance lives

Factory offset on the 5th gen sits around +4 to +15, and the 6th gen jumped to +55 to +60. Both look tucked. Going aftermarket, most 4Runner builds land between +25 for a clean daily-driver stance and -12 for the planted, fender-filling look most owners are after. On the 5th gen especially, 17x9 with a -12 offset running 33s on a modest lift is one of the most-run setups in the community. Push wider into the -18 range and plan on some liner trimming to clear at full lock. The further negative you go, the more the wheel pushes out and the more prep the truck needs to run it clean.

All 17" 18" 20"
50CAL
17x9 +0285/70R17
17x9 -12285/70R17
20x9 +0275/60R20
20x9 -12275/60R20
GRIT
17x8.5 +25275/70R17
17x9 +1285/70R17
17x9 -12285/70R17
TRAIL
17x8.5 +25275/70R17
17x9 +1285/70R17
17x9 -12285/70R17
20x9 +20275/60R20
20x9 +1275/60R20
20x10 -18 *275/60R20
COMMANDO
17x9 +0285/70R17
17x9 -12285/70R17
20x9 +0275/60R20
20x10 -18 *275/60R20
MOJAVE
17x8.5 +25275/70R17
17x9 +0285/70R17
17x9 -12285/70R17
20x9 +0275/60R20
INVADER
17x9 +25275/70R17
17x9 +0285/70R17
17x9 -12285/70R17
17x9 -38 *265/70R17
LUNATIC
17x9 +1285/70R17
18x9 +1275/70R18
18x9 -12285/65R18
20x9 +0275/60R20
20x10 -18 *275/60R20
BAJA
17x9 +0285/70R17
17x9 -12285/70R17
COMBAT
17x9 +1285/70R17
17x9 -12285/70R17
20x9 +0275/60R20
20x10 -18 *275/60R20
KRAWLER
17x9 +1285/70R17
17x9 +0285/70R17
17x9 -12285/70R17
18x9 +1275/70R18
18x9 -12285/65R18
20x9 +0275/60R20
20x10 -18 *275/60R20
OLYMPUS
17x9 -12285/70R17
17x9 -35 *265/70R17
18x9 +1275/70R18
18x9 -12285/65R18
20x9 +0275/60R20
20x10 -24 *275/60R20
ONYX
17x9 +1285/70R17
17x9 -12285/70R17
YOSEMITE
17x9 +0285/70R17
20x9 +18275/60R20
20x10 -18 *275/60R20
MATRIX
17x9 +0285/70R17
17x9 -12285/70R17
20x9 +0275/60R20
20x10 -18 *275/60R20

* Aggressive fitment. Expect to need fender liner trimming, liner removal, or bracket and bolt removal to clear at full lock, and a lift on the widest negative-offset setups. Suggested tires are a starting point from real-world 4Runner builds; confirm against your exact gen, trim, and suspension.

WILL 33s AND 35s FIT?

The 4Runner takes big tires better than most SUVs, and the answers depend on which gen you're on and how much lift you're running.

Will 33s fit a 4Runner?

Yes, on all three gens. On the 5th gen, a 285/70R17 (a true 33) fits with a modest 2 to 3-inch lift and the right offset, with light trimming of the mud flaps. Many owners run them near stock height with a leveling kit and no rubbing. On the 6th gen, TRD Pro and Trailhunter trims fit 33-inch tires (285/70R18) on factory suspension with no rubbing at all. The 4th gen fits 33s on a 2 to 2.5-inch front lift with fender liner adjustment and a wheel offset around 0 to -12.

Will 35s fit a 4Runner?

Yes, but it's a build. On the 5th gen, 35s (315/70R17 or 35x12.50R17) require roughly a 3-inch lift, upper control arms, sway bar relocation, front and rear bumper trim, and often a body mount chop. It's proven and drivable, not a bolt-on afternoon. The 6th gen makes 35s dramatically easier: the wider stance and updated geometry mean the TRD Pro and Trailhunter can fit a 295/70R18 (a true 35) on stock suspension with no rubbing reported, and higher trims fit 35s with a leveling kit. The 4th gen fits 35s with commitment: 3-inch lift minimum, body mount chop, UCAs, and body panel trimming.

Do Tacoma or Tundra wheels fit a 4Runner?

Yes, with a caveat. The Tacoma, Tundra, and 4Runner all share the 6x139.7 pattern, but the hub bore has to match your generation. 3rd gen Tacoma and 4th/5th gen 4Runner all use 106.1mm bores, so wheels cross-fit directly. 4th gen Tacoma, 3rd gen Tundra, and 6th gen 4Runner all use 95.2mm bores (some sources round to 95.1mm, same spec) with M14 studs, so those cross-fit too. Just don't mix a 106.1mm wheel with a 95.2mm-hub truck (or vice versa) without hub rings.

StockNo lift
WheelOffsetTire
17x7.5+30265/70R17
17x8.5+15275/70R17
18x7.5+55285/70R18
18x7.5+55295/70R18
Leveling Kit33s clear
WheelOffsetTire
17x8.5+0285/70R17
17x8.5-10285/70R17
17x9+0285/70R17
17x9-12285/70R17
2.5″ Lift33s planted
WheelOffsetTire
17x8.5-10285/70R17
17x9-12285/70R17
17x9-12295/70R17
35sLift + trimming
What it takes
On 4th and 5th gen, 35s take a 3″ lift, upper control arms, body mount chop, and body panel trimming. On the 6th gen, TRD Pro and Trailhunter fit 295/70R18 (a true 35) on stock suspension with no rubbing reported. 4th and 5th gen 35 setups run 17x9 -6 or -12 offset; the 6th gen keeps factory offset (+55 to +60).

33s clear on all three gens with the right combo; 35s take a lift and trimming on 4th and 5th gen, but the 6th gen TRD Pro and Trailhunter fit 35s on factory suspension. These are owner-confirmed combos; treat them as a starting point and verify against your exact gen, trim, and suspension.

LOCK WHEELS FOR YOUR 4Runner

Here's where the guide gets practical. Every wheel below is built on the right specs for the 4Runner, machined to the correct hub bore for your generation (106.1mm for 4th and 5th gen, 95.1mm for 6th gen), and drilled to the right stud pitch. That means no adapters, no hub rings, no guesswork. It seats hub-centric out of the box and holds up when the trail turns ugly.

These aren't repurposed street wheels with an off-road sticker. They're load-rated, tested on real trails, and finished to look as good in a driveway as they do covered in trail dust.

View All

Real People. Real Builds.

Specs tell you what fits. These trucks tell you how it looks when it's done right. Every build below is running Lock Off-Road wheels on a 4Runner, shot on real trails, not in a studio. Tap any photo to see the exact wheel, finish, and setup.

4Runner Wheels: FAQ

What is the bolt pattern on a Toyota 4Runner?

Every Toyota 4Runner from 1984 to today uses a 6x139.7mm (6x5.5") bolt pattern with six lugs. That part hasn't changed across any generation. What did change is the hub bore and stud size on the 6th gen (2025+).

Does the 6th gen 4Runner use a different hub bore or lug size?

Yes. The 2025 and newer 4Runner uses a 95.1mm hub bore and M14x1.5 studs. That's a change from the 4th and 5th gen 4Runner, which used a 106.1mm bore and M12x1.5 studs. The bolt pattern stayed the same at 6x139.7.

Do 5th gen 4Runner wheels fit a 6th gen?

No, not without modification. The 6th gen has a smaller 95.1mm hub bore and thicker M14 studs, so 5th gen wheels won't seat properly and the lug holes are too small for the new studs. To use 5th gen wheels on a 6th gen, you'd need to drill the wheels for M14 and add hub-centric rings to bring the bore down. Most wheel manufacturers now offer 6th-gen-specific wheels drilled and machined correctly out of the box.

What wheel offset is best for a 4Runner?

Factory offset is deep-tucked (+4 to +60 depending on gen). Most aftermarket builds run between +25 for a clean daily-driver stance and -12 for the planted, fender-filling look. The most-run setup on lifted 5th gen 4Runners is 17x9 with a -12 offset. Going further negative into the -18 range adds serious poke and needs fender liner trimming.

Will 33s fit a 4Runner?

Yes. On the 5th gen, 33s fit with a modest 2 to 3-inch lift and the right offset. TRD Pro and Trailhunter trims on the 6th gen fit 33-inch tires on factory suspension. On the 4th gen, 33s need a 2 to 2.5-inch front lift and fender liner adjustment.

Will 35s fit a 4Runner?

Yes, but with work. 5th and 4th gen setups require a 3-inch lift, upper control arms, body mount chop, and body panel trimming. The 6th gen fits 35s much more easily thanks to its wider stance: TRD Pro and Trailhunter can run 295/70R18 on stock suspension with no rubbing reported.

Do Tacoma or Tundra wheels fit a 4Runner?

Yes, because all three share the 6x139.7 bolt pattern. The 3rd gen Tacoma and 4th/5th gen 4Runner all use 106.1mm bores, so wheels cross-fit directly. The 4th gen Tacoma, 3rd gen Tundra, and 6th gen 4Runner all use ~95mm bores with M14 studs, so those cross-fit too. Don't mix bore sizes without hub rings.

What size wheels come stock on the TRD Pro, TRD Off-Road, and Trailhunter?

On the 5th gen, the TRD Pro ran 17s built around a taller off-road tire, TRD Off-Road ran 17s, and Limited trims ran 20s. On the 6th gen (2025+), the TRD Pro and Trailhunter run 18s with a +55 to +60 offset, and SR5 and TRD Off-Road run 17s.

Do I need hub rings or spacers on a 4Runner?

Spacers aren't needed for fitment, though some owners add them for stance. Hub rings matter if your wheel's bore is larger than your truck's hub. On a 4th or 5th gen (106.1mm hub), any wheel with a larger bore needs rings. On a 6th gen (95.1mm hub), any 106.1mm wheel needs rings to size down. Wheels built specifically for your gen are already machined to the right bore, so no rings are needed.
